HDMI outlet with 90° cable canvas - 30346.HC

Pdf
Vimar - 30346.HC - HDMI outlet with 90° cable canvas
Vimar - 30346.HC - HDMI outlet with 90° cable canvas

30346.HC
Wiring devices / Traditional wiring devices / LINEA / Devices

HDMI outlet with 90° cable canvas
Standard HDMI socket outlet, standard Keystone hooking, 90° cable output, canvas

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. 30346.HC
PNG DXF
rear view art. 30346.HC
PNG DXF
3D view art. 30346.HC
PNG DXF
Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
HDMI
Support ring
No
With dust cover
No
With hinged lid
No
Outlet direction
Straight
Imprintable label
Without indication field
With imprint
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
No
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Beige
RAL-number (similar)
7032
Transparent
No
Type of fastening
Clamp mounting
Number of modules (module system)
1
With buses/couplings
No
Suitable for number of connectors
1
With strain relief
No
Shielded buses
Yes
Shielded housing
Yes
Luster terminal
No
With lighting
No
Suitable for degree of protection (IP)
IP20
Device width
22,30 mm
Device height
52,80 mm
Device depth
39,40 mm

00. CE Marking - EU

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352689985
1 NR
14.2x6.2x5.6 [cm]
77 [g]
