F type female socket connector canvas - 30318.C

Pdf
Vimar - 30318.C - F type female socket connector canvas
Vimar - 30318.C - F type female socket connector canvas

30318.C
Wiring devices / Traditional wiring devices / LINEA / Devices

F type female socket connector canvas
Coaxial socket outlet with female connector type F (IEC 60169-24), canvas. For frequencies up to 2400 MHz. Connection at input and output via male connector type F 01654

Product Status
3 - Active

Drawings

view encumbered art. 30318.C
PNG DXF
rear view art. 30318.C
PNG DXF
3D view art. 30318.C
PNG DXF
Class group
Antenna and satellite technique
Class
Antenna socket box
Model
End socket
Mounting method
Flush-mounted
Number of modules (module system)
1
Cover
None
Number of outlets
1
Suitable for cable modem
No
Suitable for remote power supply
Yes
Type of fastening
Snap mounting (engagement)
Colour
Beige
RAL-number (similar)
7032
Surface protection
Untreated
Surface finishing
Matt
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Degree of protection (IP)
IP20
Device width
2.230,00 mm
Device height
5.280,00 mm
Device depth
2.985,00 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352691070
1 NR
3.6x2.7x5.6 [cm]
14.4 [g]
Barcode Qty 10 NR
8007352691087
10 NR
14.2x7.8x6.2 [cm]
182.9 [g]
Barcode Qty 160 NR
8007352691094
160 NR
34x30x15 [cm]
3,264 [g]
