TV-RD-SAT single-conn.male out. canvas - 30300.01C

Pdf
Vimar - 30300.01C - TV-RD-SAT single-conn.male out. canvas
Vimar - 30300.01C - TV-RD-SAT single-conn.male out. canvas

30300.01C
Wiring devices / Traditional wiring devices / LINEA / Devices

TV-RD-SAT single-conn.male out. canvas
TV-RD-SAT coaxial socket outlet, 5-2400 Mhz, single connection, with male connector, 1 dB connection attenuation, canvas. Allows the passage of DC current and control signals (24 V 500 mA max)

Product Status
3 - Active

Drawings

view encumbered art. 30300.01C
PNG DXF
rear view art. 30300.01C
PNG DXF
3D view art. 30300.01C
PNG DXF
Class group
Antenna and satellite technique
Class
Antenna socket box
Model
End socket
Type of socket outlet
TV/RD/SAT
DAB+
No
Mounting method
Flush-mounted
Number of modules (module system)
1
Cover
None
Tap loss at 860 MHz
0,10 dB
Tap loss at 2150 MHz
0,20 dB
Number of outlets
1
Suitable for cable modem
No
TV frequency band
5 - 2.400 MHz
Suitable for remote power supply
Yes
Radio frequency band
5 - 2.400 MHz
SAT frequency band
5 - 2.400 MHz
Shielding efficiency class
Class A
Type of fastening
Snap mounting (engagement)
Colour
Beige
RAL-number (similar)
7032
Surface protection
Untreated
Surface finishing
Matt
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Degree of protection (IP)
IP20
Device width
2.230,00 mm
Device height
5.280,00 mm
Device depth
3.210,00 mm

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352691001
1 NR
3.6x2.7x5.6 [cm]
40.7 [g]
Barcode Qty 20 NR
8007352691018
20 NR
19.4x12.6x6.5 [cm]
885.7 [g]
Barcode Qty 200 NR
8007352691025
200 NR
40x33.5x15 [cm]
9,274 [g]
Barcode Qty 7,200 NR
8007352750104
7,200 NR
120x80x105 [cm]
333,864 [g]
