Shaver supply unit 230V white - 30290.B

Pdf
Vimar - 30290.B - Shaver supply unit 230V white
Vimar - 30290.B - Shaver supply unit 230V white

30290.B
Wiring devices / Traditional wiring devices / LINEA / Devices

Shaver supply unit 230V white
Shaver socket outlet with 20 VA insulation transformer, 230 V~ 50-60 Hz power supply, 120 V~ output for 2P 15 A 125 V~ American standard non-polarised flat pin plugs and 230 V~ output for 2P 2.5 A europlugs, white - 3 modules

Product Status
3 - Active

Drawings

view encumbered art. 30290.B
PNG DXF
rear view art. 30290.B
PNG DXF
3D view art. 30290.B
PNG DXF
Class group
Domestic switching devices
Class
Razor socket outlet
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
3
Mounting method
Flush-mounted
With hinged lid
No
Voltage reversible
No
Nominal voltage low value
230 V
Nominal voltage high value
230 V
Material
Plastic
Material quality
Thermoplastic
Halogen free
No
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
Device width
67,20 mm
Device height
52,80 mm
Device depth
56,20 mm
With built-in installation box
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352702615
1 NR
11.7x10.8x7.1 [cm]
450 [g]
