Two interlocked NO+NO 10A button black - 30062.G

Pdf
Vimar - 30062.G - Two interlocked NO+NO 10A button black
Vimar - 30062.G - Two interlocked NO+NO 10A button black

30062.G
Wiring devices / Traditional wiring devices / LINEA / Devices

Two interlocked NO+NO 10A button black
Two interlocked 1P NO + 1P NO 10 A 250 V~ buttons, with direction arrows, black

Product Status
3 - Active

Drawings

view encumbered art. 30062.G
PNG DXF
rear view art. 30062.G
PNG DXF
3D view art. 30062.G
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of contacts as normally closed contact
0
Number of contacts as normally open contact
2
Number of contacts as change-over contact
0
Number of revolving contacts
0
Contactless type
No
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
With light source
No
With signal lamp
No
Feedback-signal contact
No
Connection type
Screwed terminal
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Matt
Colour
Black
RAL-number (similar)
7021
Transparent
No
Label space/information surface
No
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
52,80 mm
Device depth
29,85 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352691582
1 NR
3.6x2.7x5.6 [cm]
27.6 [g]
Barcode Qty 20 NR
8007352691599
20 NR
19.4x12.6x6.5 [cm]
617.4 [g]
Barcode Qty 200 NR
8007352691605
200 NR
40x33.5x15 [cm]
6,604 [g]
