2 buttons Flat regulation symbol nickel - 22751.3.11

Pdf
Vimar - 22751.3.11 - 2 buttons Flat regulation symbol nickel
Vimar - 22751.3.11 - 2 buttons Flat regulation symbol nickel

22751.3.11
Wiring devices / Traditional wiring devices / EIKON / Buttons

2 buttons Flat regulation symbol nickel
2 buttons Flat regulation symbol nickel

Product Status
3 - Active

Drawings

view encumbered art. 22751.3.11
PNG DXF
rear view art. 22751.3.11
PNG DXF
3D view art. 22751.3.11
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Other
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Metal
Material quality
Other
Surface protection
Metallic
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
7048
Transparent
No
Label space/information surface
Yes
Device height
15,00 mm
Device depth
8,25 mm

00. CE Marking - EU

01. IMQ - Italy

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352621329
1 NR
3.5x6.5x1.5 [cm]
9.7 [g]
Barcode Qty 20 NR
8007352621336
20 NR
14.5x11x7.5 [cm]
225.2 [g]
