2 buttons Flat w/o symbol lightable bron - 22751.12

Pdf
Vimar - 22751.12 - 2 buttons Flat w/o symbol lightable bron
Vimar - 22751.12 - 2 buttons Flat w/o symbol lightable bron

22751.12
Wiring devices / Traditional wiring devices / EIKON / Buttons

2 buttons Flat w/o symbol lightable bron
2 buttons Flat w/o symbol lightable bronze

Product Status
3 - Active

Drawings

view encumbered art. 22751.12
PNG DXF
rear view art. 22751.12
PNG DXF
3D view art. 22751.12
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Other
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Bronze
RAL-number (similar)
7010
Transparent
No
Label space/information surface
Yes
Device height
15,00 mm
Device depth
8,25 mm

00. CE Marking - EU

01. IMQ - Italy

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352620971
1 NR
3.5x6.5x1.5 [cm]
2.64 [g]
Barcode Qty 20 NR
8007352620933
20 NR
12.3x9.6x5.1 [cm]
83.77 [g]
