Plate 2M f/socket metal anthracite grey - 22642.RN.03

Pdf
Vimar - 22642.RN.03 - Plate 2M f/socket metal anthracite grey
Vimar - 22642.RN.03 - Plate 2M f/socket metal anthracite grey

22642.RN.03
Wiring devices / Traditional wiring devices / EIKON / Cover plates

Plate 2M f/socket metal anthracite grey

Product Status
3 - Active

Drawings

view encumbered art. 22642.RN.03
PNG DXF
rear view art. 22642.RN.03
PNG DXF
3D view art. 22642.RN.03
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
1
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
2
With mounting grid
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Metal
Material quality
Other
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7043
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
90,00 mm
Height
90,00 mm
Depth
10,15 mm
Built-in width
90,00 mm
Built-in height
3,00 mm

00. CE Marking - EU

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352731899
1 NR
9.5x9.5x1.4 [cm]
149 [g]
Barcode Qty 5 NR
8007352731905
5 NR
10.3x8x10.4 [cm]
778.2 [g]
