Vintage/Flat indicator unit - 22386

Pdf
Vimar - 22386 - Vintage/Flat indicator unit
Vimar - 22386 - Vintage/Flat indicator unit

22386
Wiring devices / Traditional wiring devices / EIKON / Devices

Vintage/Flat indicator unit

Product Status
3 - Active

Drawings

view encumbered art. 22386
PNG DXF
rear view art. 22386
PNG DXF
3D view art. 22386
PNG DXF
Class group
Domestic switching devices
Class
Information light signal for domestic switching devices
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Lamp holder
Other
With light source
No
Lamp type
LED exchangeable
With flashlight
No
With fixed symbol/imprint
No
With exchangeable symbol
No
Application as button
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Device width
22,3 mm
Device height
49,0 mm
Device depth
26,7 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352734487
1 NR
4.1x2.8x5.3 [cm]
18.1 [g]
Barcode Qty 10 NR
8007352734494
10 NR
14.4x9x6 [cm]
216.4 [g]
Barcode Qty 160 NR
8007352734500
160 NR
37.5x30x13.5 [cm]
3,770 [g]
