Flat/Tondo axial 1P NO 10A push mechan. - 22108

Pdf
Vimar - 22108 - Flat/Tondo axial 1P NO 10A push mechan.
Vimar - 22108 - Flat/Tondo axial 1P NO 10A push mechan.

22108
Wiring devices / Traditional wiring devices / EIKON / Devices

Flat/Tondo axial 1P NO 10A push mechan.
Axial 1P NO 10A push button mechan.Flat

Product Status
3 - Active

Drawings

view encumbered art. 22108
PNG DXF
rear view art. 22108
PNG DXF
3D view art. 22108
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Basic element with housing top
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Device height
49,00 mm
Device depth
43,70 mm

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

15. CCC - China

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352621404
1 NR
5.1x2.8x5.3 [cm]
27.4 [g]
Barcode Qty 10 NR
8007352621411
10 NR
14.4x11.6x6 [cm]
321 [g]
