Flat/Tondo axial 1P 10AX 2-way mechan. - 22104

Pdf
Vimar - 22104 - Flat/Tondo axial 1P 10AX 2-way mechan.
Vimar - 22104 - Flat/Tondo axial 1P 10AX 2-way mechan.

22104
Wiring devices / Traditional wiring devices / EIKON / Devices

Flat/Tondo axial 1P 10AX 2-way mechan.
Axial 1P 10AX 2-way switch mechan.Flat. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 22104
PNG DXF
rear view art. 22104
PNG DXF
3D view art. 22104
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device height
49,00 mm

00. CE Marking - EU

01. IMQ - Italy

13. SNI-MGI - Indonesia

15. CCC - China

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352621381
1 NR
5.1x2.8x5.3 [cm]
31.4 [g]
Barcode Qty 10 NR
8007352621398
10 NR
14.4x11.6x6 [cm]
361.7 [g]
