Two 2P+E 15A USA outlet with GFCI grey - 21296

Pdf
Vimar - 21296 - Two 2P+E 15A USA outlet with GFCI grey
Vimar - 21296 - Two 2P+E 15A USA outlet with GFCI grey

21296
Wiring devices / Traditional wiring devices / EIKON / Devices

Two 2P+E 15A USA outlet with GFCI grey
Double 2P+E 15 A 125 V~ 60 Hz socket outlet, American standard with GFCI , built-in mounting frame, to complete with 3-module cover plate, grey

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. 21296
PNG DXF
rear view art. 21296
PNG DXF
3D view art. 21296
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
No
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7024
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
With orientation lighting
No
Over voltage protection
No
Fault current protection
Yes
With miniature fuse
No
Mounting method
Flush-mounted
Type of fastening
Mounting with screw
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
125 V
Frequency
60,00 - 60,01 HZ
Rated fault current
6 mA
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
73,00 mm
Device height
107,00 mm
Device depth
41,10 mm

19. NOM - Mexico

29. QCERT - Colombia

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352503311
1 NR
6.7x5.2x12 [cm]
144.1 [g]
Barcode Qty 5 NR
8007352503328
5 NR
29.5x13.5x7.7 [cm]
795.5 [g]
Barcode Qty 95 NR
8007352503335
95 NR
55.5x37.5x29 [cm]
15,994.5 [g]
