8IN/7OUT electronic device 3M - 21126

21126
Wiring devices / Traditional wiring devices / EIKON / Devices

8IN/7OUT electronic device 3M
Electronic control with 6 independent push buttons, 8 non-polarised inputs, 7 solid state outputs for non-polarised contacts, configurable RGB LED backlighting, 9-32VDC power supply, to be completed with labels and Eikon Tactil cover plate - 3 modules

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (1303 kb)
• Manuale installatore (733 kb)
• Installer manual (754 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Electronic insert for domestic switching devices

Number of modules (module system)
3

Material
Plastic

Material quality
Thermoplastic

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352608290

1 NR

8.5x3.9x8.6 [cm]

104.4 [g]

8007352612297

10 NR

20.7x18.5x9.6 [cm]

1,152 [g]
