Two rocker push buttons+SLAVE actuator - 20529

Pdf
Vimar - 20529 - Two rocker push buttons+SLAVE actuator
Vimar - 20529 - Two rocker push buttons+SLAVE actuator

20529
Smart systems&products / By-me Plus / EIKON / Devices

Two rocker push buttons+SLAVE actuator
Two rocker push buttons and actuator for SLAVE dimmer 230 V~ 50 Hz for: LED lamps and electronic transformers, RGB lamps and electronic transformers, to complete with interchangeable 1- or 2-module buttons - 2 modules

Product Status
2 - Will be discontinued

Alternative products

01488
01488 - 4-button control+dimm.LED 240V 2M
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
200
Number of poles
1
Nominal voltage
230 V
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
44,80 mm
Device height
49,00 mm
Device depth
36,10 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352461147
1 NR
11.2x9.6x9.8 [cm]
113.7 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
