TORCIA hand lamp 120V grey - 20396

Pdf
Vimar - 20396 - TORCIA hand lamp 120V grey
Vimar - 20396 - TORCIA hand lamp 120V grey

20396
Wiring devices / Traditional wiring devices / EIKON / Devices

TORCIA hand lamp 120V grey
TORCIA, electronic hand lamp with high-efficiency LED, supply voltage 120 V~ 50-60 Hz, automatic emergency device, replaceable rechargeable Ni-MH battery, 2 hours of operating range, grey - 2 modules

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Drawings

view encumbered art. 20396
PNG DXF
rear view art. 20396
PNG DXF
3D view art. 20396
PNG DXF
Class group
Luminaires
Class
Emergency luminaire
Mounting method
Built-in
Monitoring equipment
None
With remote switch connection
No
Power supply system
Peripheral (individual battery)
Battery quality
NiMH
Lamp type
LED not exchangeable
With light source
Yes
Housing material
Plastic
Housing colour
Grey
Material cover
Without cover
Voltage type
AC
Nominal voltage
120,00 - 120,01 V
Degree of protection (IP)
IP40
Protection class
II
Max. system power
1,00 W
Width
44,80 mm
Height/depth
49,00 mm
Built-in width
44,80 mm
Built-in height/depth
46,00 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352279186
1 NR
6x5.4x5.3 [cm]
85.47 [g]
Barcode Qty 10 NR
8007352279193
10 NR
28.1x13.1x6 [cm]
936.87 [g]
