LED-emergency lamp 3M 120-230V grey - 20384

Pdf
Vimar - 20384 - LED-emergency lamp 3M 120-230V grey
Foto gallery #1
Vimar - 20384 - LED-emergency lamp 3M 120-230V grey

20384
Wiring devices / Traditional wiring devices / EIKON / Devices

LED-emergency lamp 3M 120-230V grey
Lamp with high-efficiency LED, supply voltage 120-230 V~ 50-60 Hz, automatic emergency device, 3 rechargeable AAA 1,2 V batteries, 1 hour of operating time, grey - 3 modules

  • The battery is charged continuously when powered
  • Battery charging time of 15 h, operating time after charging approximately 1 h
  • Supply voltage: 120-230 V~ ±10%, 50-60 Hz. Luminous flux: 22 lumen. Absorption: 0.5 W
  • The lamp with LED provides auxiliary lighting in the event of a power failure; when the power returns, the lamp automatically switches off and the green LED is lit

Product Status
3 - Active

Sheets, Manuals, Documentation

Drawings

view encumbered art. 20384
PNG DXF
rear view art. 20384
PNG DXF
3D view art. 20384
PNG DXF
Class group
Luminaires
Class
Emergency luminaire
Mounting method
Built-in
Monitoring equipment
None
With remote switch connection
No
Power supply system
Peripheral (individual battery)
Battery quality
NiMH
Lamp type
LED not exchangeable
With light source
Yes
Housing material
Plastic
Housing colour
Grey
Material cover
Without cover
Voltage type
AC
Nominal voltage
120,00 - 230,00 V
Degree of protection (IP)
IP40
Protection class
II
Max. system power
0,50 W
Rated luminous flux according to IEC 62722-2-1
22
Width
67,30 mm
Height/depth
46,70 mm
Built-in width
67,30 mm
Built-in height/depth
36,50 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352269699
1 NR
11.2x9.6x9.8 [cm]
166.8 [g]
