RJ12 phone jack 6/6 +cover grey - 20323

Pdf
Vimar - 20323 - RJ12 phone jack 6/6 +cover grey
Vimar - 20323 - RJ12 phone jack 6/6 +cover grey

20323
Wiring devices / Traditional wiring devices / EIKON / Devices

RJ12 phone jack 6/6 +cover grey
RJ12 phone jack with dust cover, 6-position 6-conductor (6/6), screw terminals, grey

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 20323
PNG DXF
rear view art. 20323
PNG DXF
3D view art. 20323
PNG DXF
Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
UAE/IAE (ISDN)
Support ring
No
With dust cover
Yes
With hinged lid
No
With imprint
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Type of fastening
Clamp mounting
Number of modules (module system)
1
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
43,10 mm

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352395428
1 NR
5.1x2.8x5.3 [cm]
23.5 [g]
Barcode Qty 10 NR
8007352395435
10 NR
14.4x11.6x6 [cm]
277.3 [g]
