2P+E 15A USA+SASO SICURY outlet grey - 20242

Pdf
Vimar - 20242 - 2P+E 15A USA+SASO SICURY outlet grey
Vimar - 20242 - 2P+E 15A USA+SASO SICURY outlet grey

20242
Wiring devices / Traditional wiring devices / EIKON / Devices

2P+E 15A USA+SASO SICURY outlet grey
2P+E 15 A 127 V~ SICURY socket outlet, American and Saudi Arabian standards, grey

Product Status
3 - Active

Drawings

view encumbered art. 20242
PNG DXF
rear view art. 20242
PNG DXF
3D view art. 20242
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7024
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
22,30 mm
Device height
49,00 mm
Device depth
36,90 mm

00. CE Marking - EU

29. QCERT - Colombia

34. PSE - Japan

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352281943
1 NR
4.1x2.8x5.3 [cm]
29.2 [g]
Barcode Qty 20 NR
8007352281950
20 NR
21.4x11.6x6 [cm]
643 [g]
Barcode Qty 460 NR
8007352626232
460 NR
57.5x22.5x30 [cm]
15,209 [g]
