IR relay-receiver for blind grey - 20173

20173
Wiring devices / Traditional wiring devices / EIKON / Devices

IR relay-receiver for blind grey
Infrared receiver with 4 A 230 V~ relay output for roller blinds, control with built-in push buttons, 01849 remote control or from peripheral NO push buttons, mono-or-bistable mode, visible in darkness, supply voltage 230 V~ 50-60 Hz, grey - 2 modules

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (545 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Electronic insert for domestic switching devices

Model
Other

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
2

Radio-controlled
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 5 NR

---

Barcode

8007352269514

1 NR

6x5.4x5.3 [cm]

74.53 [g]

8007352269521

5 NR

17.2x13.1x6 [cm]

432 [g]
