RGB dimmer 230V grey - 20138

Pdf
Vimar - 20138 - RGB dimmer 230V grey
Vimar - 20138 - RGB dimmer 230V grey

20138
Wiring devices / Traditional wiring devices / EIKON / Devices

RGB dimmer 230V grey
RGB dimmer 230 V~ 50 Hz for: RGB LED lamps, RGB LED electronic transfomers (01876), ON/OFF and brightness control with built-in push button or from peripheral NO push buttons, colour control via rotary potentiometer, visible in darkness, grey. Not for Isoset enclosures

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Video

Drawings

view encumbered art. 20138
PNG DXF
rear view art. 20138
PNG DXF
3D view art. 20138
PNG DXF
Class group
Domestic switching devices
Class
Dimmer
Method of operation
Turn button
Type of load
Other
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 V
Frequency
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 V
Device width
22,30 mm
Device height
49,00 mm
Device depth
61,00 mm

00. CE Marking - EU

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352469020
1 NR
5.2x3.9x6.2 [cm]
59.9 [g]
Barcode Qty 5 NR
8007352469037
5 NR
14.4x11.6x6 [cm]
343.5 [g]
