Axial 1P 16AX reversing switch grey - 20113

Pdf

Vimar - 20113 - Axial 1P 16AX reversing switch grey

20113
Wiring devices / Traditional wiring devices / EIKON / Devices

Axial 1P 16AX reversing switch grey
Axial 1P 16 AX 250 V~ reversing switch, lightable, replaceable button, grey. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

You may also be interested in

00938.A - LED unit 110-250V 0,3Waxialcontrol amber

00938.G - LED unit 110-250V 0,3Waxialcontrol green

00938.R - LED unit 110-250V 0,3Waxialcontrol red

00938.B - LED unit 110-250V 0,3Waxialcontrol blue

00938.W - LED unit 110-250V 0,3Waxialcontrol white

Drawings

view encumbered art. 20113

PNG DXF

rear view art. 20113

PNG DXF

3D view art. 20113

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Intermediate switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
0

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Label space/information surface
Yes

Illumination
Optional

Function lighting
Control and orientation

Type of lighting
LED exchangeable

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device width
22,30 mm

Device height
49,00 mm

Device depth
44,00 mm

Built-in depth
34,50 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352460126

1 NR

5.1x2.8x5.3 [cm]

37.1 [g]

8007352460133

20 NR

27x11.6x6 [cm]

811.5 [g]

8007352651371

120 NR

37.5x30x13.5 [cm]

5,220 [g]
