Axial 1P NO 10A push button grey - 20108

Pdf
Vimar - 20108 - Axial 1P NO 10A push button grey
Vimar - 20108 - Axial 1P NO 10A push button grey

20108
Wiring devices / Traditional wiring devices / EIKON / Devices

Axial 1P NO 10A push button grey
Axial 1P NO 10 A 250 V~ push button, lightable, replaceable button, grey

Product Status
3 - Active

You may also be interested in

00938.A
00938.A - LED unit 110-250V 0,3Waxialcontrol amber
00938.G
00938.G - LED unit 110-250V 0,3Waxialcontrol green
00938.R
00938.R - LED unit 110-250V 0,3Waxialcontrol red
00938.B
00938.B - LED unit 110-250V 0,3Waxialcontrol blue
00938.W
00938.W - LED unit 110-250V 0,3Waxialcontrol white

Drawings

view encumbered art. 20108
PNG DXF
rear view art. 20108
PNG DXF
3D view art. 20108
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
44,00 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352460003
1 NR
5.1x2.8x5.3 [cm]
29.1 [g]
Barcode Qty 20 NR
8007352460010
20 NR
27x11.6x6 [cm]
650.1 [g]
Barcode Qty 120 NR
8007352651241
120 NR
37.5x30x13.5 [cm]
4,260 [g]
