1P NO 10A push +green indicator white - 20068.V.B

Pdf
Vimar - 20068.V.B - 1P NO 10A push +green indicator white
Vimar - 20068.V.B - 1P NO 10A push +green indicator white

20068.V.B
Wiring devices / Traditional wiring devices / EIKON / Devices

1P NO 10A push +green indicator white
1P NO 10 A 250 V~ push button + indicator unit for signalling unit, green diffuser, white. Provided without signalling unit

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 20068.V.B
PNG DXF
rear view art. 20068.V.B
PNG DXF
3D view art. 20068.V.B
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
38,50 mm

00. CE Marking - EU

14. TSE - Turkey

29. QCERT - Colombia

37. Marking - Morocco

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352315778
1 NR
4.1x2.8x5.3 [cm]
31.4 [g]
Barcode Qty 10 NR
8007352315785
10 NR
14.4x9x6 [cm]
348.53 [g]
