2P 10A 2-way push button Next - 20061.N

Pdf
Vimar - 20061.N - 2P 10A 2-way push button Next
Vimar - 20061.N - 2P 10A 2-way push button Next

20061.N
Wiring devices / Traditional wiring devices / EIKON / Devices

2P 10A 2-way push button Next
2P 10 A 250 V~ 2-way push button (6 terminals) with directional arrows and central OFF position, Next

Product Status
3 - Active

Drawings

view encumbered art. 20061.N
PNG DXF
rear view art. 20061.N
PNG DXF
3D view art. 20061.N
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
43,50 mm

00. CE Marking - EU

01. IMQ - Italy

20. IQC - Argentina

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352571259
1 NR
5.1x2.8x5.3 [cm]
42.8 [g]
Barcode Qty 10 NR
8007352571266
10 NR
14.4x11.6x6 [cm]
471.4 [g]
