2P 10A 2-way push button grey - 20061

Pdf
Vimar - 20061 - 2P 10A 2-way push button grey
Vimar - 20061 - 2P 10A 2-way push button grey

20061
Wiring devices / Traditional wiring devices / EIKON / Devices

2P 10A 2-way push button grey
2P 10 A 250 V~ 2-way push button (6 terminals) with directional arrows and central OFF position, grey

Product Status
3 - Active

Drawings

view encumbered art. 20061
PNG DXF
rear view art. 20061
PNG DXF
3D view art. 20061
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
2
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
43,50 mm

00. CE Marking - EU

01. IMQ - Italy

20. IQC - Argentina

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352571211
1 NR
5.1x2.8x5.3 [cm]
42.6 [g]
Barcode Qty 10 NR
8007352571228
10 NR
14.4x11.6x6 [cm]
470.7 [g]
