Button 2M O/I symbol Next - 20022.99.N

20022.99.N
Wiring devices / Traditional wiring devices / EIKON / Buttons

Button 2M O/I symbol Next
Interchangeable 2-module button, lightable O I symbols, for 2P 1-way swicth mechanism, Next

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Control element/cover plate for domestic switching devices

Model
One-part rocker

Imprint/indication
Characters 0 and 1

Utilization
Switch/push button

Suitable for touch sensor connector for bus system
No

Type of fastening
Clamp mounting

Monitoring window/light outlet
Yes

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Lacquered

Surface finishing
Matt

Colour
Silver

RAL-number (similar)
9022

With label area
No

With exchangeable lens/symbol
No

Suitable for degree of protection (IP)
IP40

Depth
1.115,00 mm

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

96. Electrotechnical expert

Minimum order quantity: 2 NR

---

Barcode

8007352284999

1 NR

4.46x4.9x2.29 [cm]

8.6 [g]

8007352285002

2 NR

5.1x2.8x5.3 [cm]

21 [g]

8007352730793

20 NR

14.4x11.6x6 [cm]

210 [g]
