Button 1M bell symbol grey - 20021.C

Pdf
Vimar - 20021.C - Button 1M bell symbol grey
Foto gallery #1
Foto gallery #2
Vimar - 20021.C - Button 1M bell symbol grey

20021.C
Wiring devices / Traditional wiring devices / EIKON / Buttons

Button 1M bell symbol grey
Interchangeable 1-module button, lightable bell symbol, grey

Product Status
3 - Active

Drawings

view encumbered art. 20021.C
PNG DXF
rear view art. 20021.C
PNG DXF
3D view art. 20021.C
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
One-part rocker
Imprint/indication
Symbol ˝bell˝
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Depth
600,00 mm

00. CE Marking - EU

01. IMQ - Italy

29. QCERT - Colombia

96. Electrotechnical expert

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352252516
1 NR
2.2x4.42x0.6 [cm]
2.6 [g]
Barcode Qty 5 NR
8007352252523
5 NR
4.1x2.8x5.3 [cm]
17 [g]
Barcode Qty 50 NR
8007352731158
50 NR
14.4x9x6 [cm]
170 [g]
