1P NC 10A push button grey - 20010

Pdf

Vimar - 20010 - 1P NC 10A push button grey

20010
Wiring devices / Traditional wiring devices / EIKON / Devices

1P NC 10A push button grey
1P NC 10 A 250 V~ push button, lightable, replaceable button, grey

Product Status
3 - Active

Drawings

view encumbered art. 20010

PNG DXF

rear view art. 20010

PNG DXF

3D view art. 20010

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
1

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
Yes

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7024

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
36,15 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352250987

1 NR

4.1x2.8x5.3 [cm]

26.2 [g]

8007352250994

20 NR

21.4x11.6x6 [cm]

580.93 [g]

8007352649194

300 NR

37x28.5x25 [cm]

9,162 [g]
