IoT connected device mechanism - 19591.0

Pdf

Vimar - 19591.0 - IoT connected device mechanism

19591.0
Wiring devices / View Wireless wiring devices / ARKÉ / Devices

IoT connected device mechanism

Product Status
3 - Active

You may also be interested in

19755 - 2 half buttons 1M customizable grey

19755.2 - 2 half buttons 1M arrows symbol grey

19755.2.B - 2 half buttons 1M arrows symbol white

19755.2.M - 2 half buttons 1M arrows symbol Metal

19755.3 - 2 half buttons 1M dimmer grey

19755.3.B - 2 half buttons 1M dimmer white

19755.3.M - 2 half buttons 1M dimmer Metal

19755.6 - 2 half buttons 1M scenario symbol grey

19755.6.B - 2 half buttons 1M scenario symbol white

19755.6.M - 2 half buttons 1M scenario symbol Metal

19755.B - 2 half buttons 1M customizable white

19755.M - 2 half buttons 1M customizable Metal

Sheets, Manuals, Documentation

Drawings

view encumbered art. 19591.0

PNG DXF

rear view art. 19591.0

PNG DXF

3D view art. 19591.0

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Other

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
No

Anti-bacterial treatment
No

Surface protection
Untreated

Surface finishing
Matt

Colour
Blue

RAL-number (similar)
7015

Label space/information surface
No

Illumination
Yes

Function lighting
Other

Type of lighting
LED not exchangeable

Suitable for degree of protection (IP)
IP40

Switching current for fluorescent lamps
0

Feedback-signal contact
No

Connection type
Screwed terminal

Heating switch
No

Washing machine switch
No

Device width
22,20 mm

Device height
49,00 mm

Built-in depth
36,50 mm

Min. depth of built-in installation box
40,00 mm

Compatible with Apple HomeKit
No

Compatible with Google Assistant
No

Compatible with Amazon Alexa
No

IFTTT support available
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

40. Bluetooth technology

46. UK PSTI compliance

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

8007352707634

1 NR

6x5.4x5.2 [cm]

34 [g]

8007352707641

60 NR

37.5x30x13.5 [cm]

2,254 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
