Vimar - 19485 - IR motion detector grey

19485
Smart systems&products / By-me Plus / ARKÉ / Devices

IR motion detector grey
Passive infrared motion detector, grey - 2 modules

Product Status
3 - Active

Class group
Installation bus systems
Class
Movement sensor for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Movement sensor
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
With bus connection
Yes
Substation input
No
Creep-under protection
No
Operation mode switch
No
Animal zone
No
Staircase light controller
No
Response value luminosity adjustable
Yes
Teach-function for response value luminosity
No
Switch-off delay self-learning
No
DALI-2 certified
No
Optimum mounting height
1,20 m
Max. reach sideways
0,00 m
Max. reach frontally
10 m
Diameter reach on floor
0 m
Detection angle vertical
0 - 36
Detection angle horizontal
0,00 - 112,00
Number of channels
1
Switching power
0 W
Min. switch-on time
10 s
Max. duty cycle
250 min
Min. depth of built-in installation box
30 mm

00. CE Marking - EU

01. IMQ - Italy

01. IMQ - Italy

37. Marking - Morocco

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352451025
1 NR
11.2x9.6x9.8 [cm]
107.9 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
