Connected NFC/RFID switch white - 19467.B

Pdf
Vimar - 19467.B - Connected NFC/RFID switch white
Vimar - 19467.B - Connected NFC/RFID switch white

19467.B
Wiring devices / View Wireless wiring devices / ARKÉ / Devices

Connected NFC/RFID switch white
NFC/RFID smart card reader pocket for installation inside the room, IoT technology on Bluetooth technology 5.0 standard for the creation of View Wireless mesh system, 1 relay output NO 16 A 120-240 V~ 50/60 Hz, 1 configurable input, LED visible in darkness with brightness control, 100-240 V~ 50/60 Hz power supply, white - 2 modules.

Product Status
3 - Active

Class group
Alarm installations, emergency call and signalling
Class
Access control system
Standalone
Yes
Networkable
No
PC-binding
No
Type of interface
Other
Max. number of persons
200
Reading strategy
Code
Signalling
Light signal
Mounting method
Flush-mounted
Operating voltage AC 50 Hz
120,00 - 230,00 V
Operating voltage AC 60 Hz
120,00 - 230,00 V
Operating temperature
0 - 40 °C
Degree of protection (IP)
IP20
Colour
White
Model
Reader
Material
Plastic
Power over Ethernet (PoE)
Other
Width
67,30 mm
Height
49,00 mm
Depth
50,30 mm

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352661677
1 NR
5.7x5.3x7.7 [cm]
84.8 [g]
Barcode Qty 5 NR
8007352663664
5 NR
21.4x11.6x6 [cm]
479.2 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
