9P SUB D socket connector grey - 19365

Pdf
Vimar - 19365 - 9P SUB D socket connector grey
Foto gallery #1
Foto gallery #2
Foto gallery #3
Foto gallery #4
Foto gallery #5
Foto gallery #6
Vimar - 19365 - 9P SUB D socket connector grey

19365
Wiring devices / Traditional wiring devices / ARKÉ / Devices

9P SUB D socket connector grey
9-pin socket connector, SUB D, soldering, grey - 2 modules

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
D-sub-miniature
Support ring
No
With dust cover
No
With hinged lid
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Number of modules (module system)
2
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP20
Device width
44,80 mm
Device height
49,00 mm
Device depth
20,10 mm

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352436558
1 NR
5.1x2.8x5.3 [cm]
21.1 [g]
Barcode Qty 5 NR
8007352436565
5 NR
14.2x6.7x5.9 [cm]
135.7 [g]
