2P+E 13A SICURY multi-outlet+switch grey - 19255

Pdf
Vimar - 19255 - 2P+E 13A SICURY multi-outlet+switch grey
Vimar - 19255 - 2P+E 13A SICURY multi-outlet+switch grey

19255
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P+E 13A SICURY multi-outlet+switch grey
2P+E 13 A 250 V~ SICURY socket outlet, multi standard with 1P 1-way switch, lightable, grey - 3 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of modules (module system)
2
Number of socket outlets switchable
1
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
Yes
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
Yes
Rotated central insert
No
Nominal current
13 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
67,30 mm
Device height
49,00 mm
Device depth
31,10 mm

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352599406
1 NR
5.3x3.9x7.6 [cm]
65.6 [g]
Barcode Qty 10 NR
8007352599413
10 NR
28.1x13.1x6 [cm]
739 [g]
Barcode Qty 120 NR
8007352716964
120 NR
38.5x29x30 [cm]
8,868 [g]
