2P+E 15A USA+SASO SICURY outlet grey - 19242

Pdf
Vimar - 19242 - 2P+E 15A USA+SASO SICURY outlet grey
Vimar - 19242 - 2P+E 15A USA+SASO SICURY outlet grey

19242
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P+E 15A USA+SASO SICURY outlet grey
2P+E 15 A 127 V~ SICURY socket outlet, American and Saudi Arabian standards, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
22,30 mm
Device height
49,00 mm
Device depth
36,90 mm

00. CE Marking - EU

29. QCERT - Colombia

34. PSE - Japan

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352471269
1 NR
4.1x2.8x5.3 [cm]
29 [g]
Barcode Qty 20 NR
8007352471276
20 NR
21.4x11.6x6 [cm]
638.2 [g]
Barcode Qty 300 NR
8007352644595
300 NR
37x28.5x25 [cm]
10,032 [g]
