2P+E10A Swiss 13 SICURY outlet grey - 19226

Pdf
Vimar - 19226 - 2P+E10A Swiss 13 SICURY outlet grey
Vimar - 19226 - 2P+E10A Swiss 13 SICURY outlet grey

19226
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P+E10A Swiss 13 SICURY outlet grey
2P+E 10 A 250 V~ socket outlet, Swiss standard, 13 type, grey - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Swiss norm type 13
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
10 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
44,80 mm
Device height
49,00 mm
Device depth
46,25 mm

00. CE Marking - EU

05. SEV - Switzerland

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352450837
1 NR
6x5.4x5.3 [cm]
41.9 [g]
Barcode Qty 20 NR
8007352450844
20 NR
28.1x13.1x11.3 [cm]
937.2 [g]
