Vimar - 19201 - 2P+E 10A P11 outlet grey

19201
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P+E 10A P11 outlet grey
2P+E 10 A 250 V~ SICURY socket outlet, Italian standard P11, grey

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Italian type P11
Number of units
1
Number of modules (module system)
1
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
With orientation lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Type of fastening
Snap mounting (engagement)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
10 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
22,30 mm
Device height
49,00 mm
Device depth
25,00 mm

00. CE Marking - EU

01. IMQ - Italy

07. INGCER - Chile

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352414280
1 NR
4.1x2.8x5.3 [cm]
29.8 [g]
Barcode Qty 50 NR
8007352414297
50 NR
21.6x11.6x14.3 [cm]
1,590 [g]
Barcode Qty 500 NR
8007352414303
500 NR
57.5x22.5x30 [cm]
16,358 [g]
Barcode Qty 10,500 NR
8007352482555
10,500 NR
80x120x103 [cm]
352,800 [g]
