Dimmer 230V 100-500W grey - 19150

Pdf

Vimar - 19150 - Dimmer 230V 100-500W grey

19150
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Dimmer 230V 100-500W grey
Dimmer 230 V~ 50-60 Hz for: 100-500 W incandescent lamps, control and regulation by rotary potentiometer, visible in darkness, grey

Product Status
3 - Active

Sheets, Manuals, Documentation

Multilanguage instructions sheet (626 kb)

Video

Arké lives in your time

Drawings

view encumbered art. 19150

PNG DXF

rear view art. 19150

PNG DXF

3D view art. 19150

PNG DXF

Class group
Domestic switching devices

Class
Dimmer

Method of operation
Turn button

Type of load
Resistive load

Applicable with button
No

Applicable with movement sensor
No

Applicable with presence indicator
No

Applicable with time switch/timer
No

Applicable with transmission button
No

Applicable with infrared button
No

Mounting method
Flush-mounted

Type of fastening
Snapper mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Transparent
No

Suitable for degree of protection (IP)
IP40

Nominal voltage
230,00 - 230,01 V

Frequency
50,00 - 60,00 HZ

Control voltage
230,00 - 230,01 V

Device width
22,30 mm

Device height
49,00 mm

Device depth
60,50 mm

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352414167

1 NR

6x2.8x5.3 [cm]

57.3 [g]

8007352414174

20 NR

28.1x13.1x6 [cm]

1,229 [g]

8007352657397

240 NR

38.5x29x30 [cm]

14,748 [g]
