Universal MASTER dimmer 230V grey - 19135.1

Pdf
Vimar - 19135.1 - Universal MASTER dimmer 230V grey
Vimar - 19135.1 - Universal MASTER dimmer 230V grey

19135.1
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Universal MASTER dimmer 230V grey
Universal-dimmer 230 V~ 50 Hz, phase-cutting, for: 40-400 W incandescent lamps, 40-300 VA electronic transfomers, 10-200 W CFL lamps, 3-200 W LED lamps, LED phase-cutting electronic transfomers, ON/OFF control and built-in or from NO peripheral push buttons regulation, MASTER function for 19137, minimum brightness regulation, visible in darkness, grey. Not for Isoset enclosures

Product Status
3 - Active

Class group
Domestic switching devices
Class
Dimmer
Method of operation
Push button
Type of load
Universal and LED Retrofit
Applicable with button
Yes
Applicable with movement sensor
No
Applicable with presence indicator
No
Applicable with time switch/timer
No
Applicable with transmission button
No
Applicable with infrared button
No
Mounting method
Flush-mounted
Type of fastening
Snapper mounting
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Suitable for degree of protection (IP)
IP40
Nominal voltage
230,00 - 230,01 V
Frequency
50,00 - 50,01 HZ
Control voltage
230,00 - 230,01 V
Connection type
Screwed terminal
Device width
22,30 mm
Device height
49,00 mm
Device depth
50,70 mm

00. CE Marking - EU

01. IMQ - Italy

31. TISI - Thailand

37. Marking - Morocco

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352555792
1 NR
5.1x4.3x5.3 [cm]
54.4 [g]
Barcode Qty 10 NR
8007352555808
10 NR
26.9x11.6x4.9 [cm]
610 [g]
