Axial 1P 10AX 2-way switch grey - 19104

Pdf
Vimar - 19104 - Axial 1P 10AX 2-way switch grey
Vimar - 19104 - Axial 1P 10AX 2-way switch grey

19104
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Axial 1P 10AX 2-way switch grey
Axial 1P 10 AX 250 V~ 2-way switch, lightable, replaceable button, grey. Max 100 W for lamps with built-in power unit (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 19104
PNG DXF
rear view art. 19104
PNG DXF
3D view art. 19104
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Other
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
0
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No

00. CE Marking - EU

01. IMQ - Italy

15. CCC - China

28. NSW - Australia

29. QCERT - Colombia

36. ISI - India

37. Marking - Morocco

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352684645
1 NR
5.1x2.8x5.3 [cm]
32.2 [g]
Barcode Qty 20 NR
8007352684652
20 NR
27x11.6x6 [cm]
709.4 [g]
Barcode Qty 120 NR
8007352684669
120 NR
37.5x30x13.5 [cm]
4,616.4 [g]
