2P NO 16A push button +key grey - 19086

Pdf

Vimar - 19086 - 2P NO 16A push button +key grey

19086
Wiring devices / Traditional wiring devices / ARKÉ / Devices

2P NO 16A push button +key grey
2P NO 16 A 250 V~ key-operated push button, key removable in OFF position only, grey

Product Status
3 - Active

Video

Arké lives in your time

Drawings

view encumbered art. 19086

PNG DXF

rear view art. 19086

PNG DXF

3D view art. 19086

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
0

Number of modules (module system)
100

Number of poles
2

Nominal voltage
250 V

Rated current
16,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
43,50 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352414105

1 NR

5.1x2.8x5.3 [cm]

57.2 [g]

8007352414112

20 NR

27x11.6x6 [cm]

1,209 [g]
