Two independent NO+NC 10A pushes grey - 19058

Pdf

Vimar - 19058 - Two independent NO+NC 10A pushes grey

19058
Wiring devices / Traditional wiring devices / ARKÉ / Devices

Two independent NO+NC 10A pushes grey
Two independent push buttons, 1P NO + 1P NC 10 A 250 V~, ON and OFF symbols, grey

Product Status
3 - Active

Video

Arké lives in your time

Drawings

view encumbered art. 19058

PNG DXF

rear view art. 19058

PNG DXF

3D view art. 19058

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Other

Method of operation
Push button

Number of rockers
2

Number of modules (module system)
100

Number of poles
1

Nominal voltage
250 V

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Transparent
No

Label space/information surface
Yes

Suitable for degree of protection (IP)
IP40

Device width
22,30 mm

Device height
49,00 mm

Device depth
29,00 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

19. NOM - Mexico

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352413948

1 NR

4.1x2.8x5.3 [cm]

32.9 [g]

8007352413955

20 NR

21.4x11.6x6 [cm]

715 [g]
