1P 16AX 2-way switch 2M Metal - 19005.2.M

Pdf
Vimar - 19005.2.M - 1P 16AX 2-way switch 2M Metal
Vimar - 19005.2.M - 1P 16AX 2-way switch 2M Metal

19005.2.M
Wiring devices / Traditional wiring devices / ARKÉ / Devices

1P 16AX 2-way switch 2M Metal
1P 16 AX 250 V~ 2-way switch, lightable, replaceable button, Metal - 2 modules. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
2 - Will be discontinued

Alternative products

19004.2.M
19004.2.M - 1P 10AX 2-way switch 2M Metal
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9007
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
44,80 mm
Device height
49,00 mm
Device depth
36,80 mm
Built-in depth
25,00 mm

00. CE Marking - EU

01. IMQ - Italy

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW - Australia

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

47. SASO - Saudi Arabia

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352593893
1 NR
5.1x4.3x5.3 [cm]
36.7 [g]
Barcode Qty 20 NR
8007352593909
20 NR
26.9x11.6x9 [cm]
808.6 [g]
Barcode Qty 240 NR
8007352648104
240 NR
38x28.5x35.5 [cm]
10,212 [g]
