1P NO 10A push general symbol 2M grey - 17010.G

Pdf
Vimar - 17010.G - 1P NO 10A push general symbol 2M grey
Vimar - 17010.G - 1P NO 10A push general symbol 2M grey

17010.G
Wiring devices / Traditional wiring devices / IDEA / Devices

1P NO 10A push general symbol 2M grey
1P NO 10 A 250 V~ push button, general symbol, grey - 2 reduced modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
200
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
21,80 mm
Device height
50,10 mm
Device depth
32,50 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352084285
1 NR
5.1x4.3x5.3 [cm]
31.87 [g]
Barcode Qty 20 NR
8007352084292
20 NR
26.9x11.6x9 [cm]
720.47 [g]
