1P NO 10A push general symbol white - 17010.B

Pdf
Vimar - 17010.B - 1P NO 10A push general symbol white
Vimar - 17010.B - 1P NO 10A push general symbol white

17010.B
Wiring devices / Traditional wiring devices / IDEA / Devices

1P NO 10A push general symbol white
1P NO 10 A 250 V~ push button, general symbol, white - reduced module

Product Status
3 - Active

Drawings

view encumbered art. 17010.B
PNG DXF
rear view art. 17010.B
PNG DXF
3D view art. 17010.B
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9001
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
21,80 mm
Device height
50,10 mm
Device depth
32,50 mm

00. CE Marking - EU

01. IMQ - Italy

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352064218
1 NR
4.1x2.8x5.3 [cm]
22.2 [g]
Barcode Qty 20 NR
8007352064232
20 NR
21.4x11.6x6 [cm]
504.4 [g]
