2P 10AX 1-way switch grey

Pdf

Vimar - 17007 - 2P 10AX 1-way switch grey

17007
Wiring devices / Traditional wiring devices / IDEA / Devices

2P 10AX 1-way switch grey
2P 16 AX 250 V~ 1-way switch, grey - reduced module. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices

Class
Installation switch

Wiring system
2-pole switch

Method of operation
Rocker/button

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Thermoplastic

Halogen free
Yes

Surface protection
Untreated

Surface finishing
Matt

Colour
Grey

RAL-number (similar)
7015

Label space/information surface
Yes

Illumination
No

Function lighting
Other

Type of lighting
Other

Suitable for degree of protection (IP)
IP40

Nominal voltage
250 V

Rated current
16,00 A

Feedback-signal contact
No

Connection type
Screwed terminal

Washing machine switch
Yes

Device width
21,80 mm

Device height
50,10 mm

Device depth
36,50 mm

Built-in depth
23,30 mm

00. CE Marking - EU

14. TSE - Turkey

19. NOM - Mexico

28. NSW - Australia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

8007352005631

1 NR

5.1x2.8x5.3 [cm]

33 [g]

8007352005648

20 NR

27x11.6x6 [cm]

731.07 [g]

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
