Three rocker push buttons+relay grey - 16986

Pdf
Vimar - 16986 - Three rocker push buttons+relay grey
Vimar - 16986 - Three rocker push buttons+relay grey

16986
Smart systems&products / By-me Plus / IDEA / Devices

Three rocker push buttons+relay grey
Three rocker push buttons and actuator with 8 A 120-230 V~ change-over relay output, to complete with interchangeable 1- or 2-module buttons, grey - 3 modules

Product Status
2 - Will be discontinued

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
3
Number of modules (module system)
300
Number of poles
1
Nominal voltage
230 V
Rated current
8,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Device width
74,80 mm
Device height
50,10 mm
Device depth
44,95 mm

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352344860
1 NR
11.2x9.6x9.8 [cm]
157.6 [g]
