KNX thermostat grey - 16915

Pdf
Vimar - 16915 - KNX thermostat grey
Vimar - 16915 - KNX thermostat grey

16915
Smart systems&products / KNX / IDEA / Devices

KNX thermostat grey
Electronic thermostat for ON/OFF ambient temperature control (heating and air conditioning) of 2 independent zones, KNX standard home automation system, class I temperature control device (contribution 1%),1 NO relay output 4 A 24 V~, 1 input for temperature sensor compatible with 20432, 19432 or 14432, 1 programmable digital input, grey - 2 modules

Product Status
3 - Active

Class group
Installation bus systems
Class
Room temperature controller for bus system
Bus system KNX
Yes
Bus system KNX-RF (Radio Frequency)
No
Bus system radio frequency
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
None
Radio frequency bidirectional
No
Assembly arrangement
Other
Mounting method
Flush-mounted
With local operation
Yes
With anti-theft/dismantling protection
No
With LED indication
No
With display
Yes
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7015
Transparent
No
Manual set point setting
Yes
Presence button
No
Degree of protection (IP)
IP40
With bus connection
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352420939
1 NR
11.2x9.6x9.8 [cm]
150.7 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
