16723
Wiring devices / Traditional wiring devices / IDEA / Mounting frames
Frame 3M Arké idea+screws grey
3-module mounting frame, with screws, for 2-module Arké devices installation on Idea cover plates, for 3-module mounting boxes, grey
Product Status
3 - Active
You may also be interested in
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Mounting with screw
Mounting with screw
Mounting method of the module inserts
Front side
Front side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Minimum order quantity: 20 NR
Barcode
8007352533820
1 NR
11.8x7.5x2.5 [cm]
22.2 [g]
8007352533837
20 NR
28x15.2x9.75 [cm]
536 [g]
| Question: | The timer-thermostat replacing an Idea thermostat 16580 will not adapt to the cover plate for surface mounting. |
|---|---|
| Answer: | In order to install the Idea cover plate, simply purchase the mounting frame code 16723 - Arké Idea 3M mounting frame + grey screws. |
