16713
Wiring devices / Traditional wiring devices / IDEA / Mounting frames
Frame 3M +screws
3-module mounting frame, with screws, for 3-module mounting boxes, grey
Product Status
3 - Active
You may also be interested in
Drawings
Class group
Domestic switching devices
Domestic switching devices
Class
Holder for modular domestic switching devices
Holder for modular domestic switching devices
Model
Flush-mounted
Flush-mounted
Mounting method
Mounting with screw
Mounting with screw
Mounting method of the module inserts
Back side
Back side
Mounting direction
Horizontal and vertical
Horizontal and vertical
Number of modules horizontal (module system)
3
3
Number of modules vertical (module system)
1
1
With built-in installation box
No
No
With screws
Yes
Yes
Suitable for mounting in round junction box 60 mm
No
No
Flush-mounted installation
Yes
Yes
Suitable for subfloor installation duct box
No
No
Suitable for wall duct
No
No
Suitable for mounting on DIN-rail 35 mm
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Minimum order quantity: 20 NR
Barcode
8007352045477
1 NR
11.4x7.5x1.5 [cm]
23.2 [g]
8007352147249
10 NR
11.4x7.5x15 [cm]
228.13 [g]
8007352631410
20 NR
28.4x18.4x7.5 [cm]
554.6 [g]
8007352631427
240 NR
59x38.5x24 [cm]
7,306 [g]
8007352654402
7,680 NR
120x80x185 [cm]
190,924.8 [g]
| Question: | Are the Idea Rondo plaques compatible with the devices and mounting supports of the Idea Classic plaques? |
|---|---|
| Answer: | The Idea series has devices and mounting supports that can be completed with both Classic plaques and Rondo plaques. The Rondo plaques are not compatible with the following parts (thus require Classic plaques):-16803 and 16806 table mounting box-16813 mounting bracket-09975.A surface mounting box-16570.SZ and 16570.SZ.B mounting support for infrared remote control. |
