2P+E 16A universal outlet grey - 16210

Pdf
Vimar - 16210 - 2P+E 16A universal outlet grey
Vimar - 16210 - 2P+E 16A universal outlet grey

16210
Wiring devices / Traditional wiring devices / IDEA / Devices

2P+E 16A universal outlet grey
2,5 A Europlugs, 2P and 2P+E 10 A and 16 A Italian standard plugs, 2P+E 16 A German standard plugs, 2P 15 A 125 V~ American standard plugs with non-polarized flat blades, grey - 2 modules. Earth connection is not realized with 2P+E 16 A 250 V~ French standard plug

Product Status
2 - Will be discontinued

Drawings

view encumbered art. 16210
PNG DXF
rear view art. 16210
PNG DXF
3D view art. 16210
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
Other
Number of units
1
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
Grey
RAL-number (similar)
7015
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With loop through function
No
With on/off switch
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 V
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Device width
49,80 mm
Device height
50,10 mm
Device depth
41,90 mm

00. CE Marking - EU

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352000858
1 NR
5.1x4.3x5.3 [cm]
57.07 [g]
Barcode Qty 20 NR
8007352001619
20 NR
26.9x11.6x9 [cm]
1,225.07 [g]
Barcode Qty 240 NR
8007352263208
240 NR
38x28.5x35.5 [cm]
15,280 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
